Sprinter Crew Van
Starting at
$46,700
**
Color
Arctic WhiteCrew Van Lineup
2023
Dimensions

- Overall Height:
- 96.3 in
- Overall Length:
- 233.5 in
- Overall Width with mirrors:
- 92.3 in
- Wheelbase:
- 144 in
Key Features
- Engine:
- 4-Cylinder Gas
- Payload Capacity:
- 4,068 lbs
- Max Towing:
- 5,000 lbs [1]
- Cargo Volume:
- 222.5
- Standing Height:
- 65.3 in
- Seating Capacity:
- 5
Capacity
- Payload Capacity:
- 4,068 lbs
- Seating Capacity:
- 5
- Cargo Volume:
- 222.5
- Max Available GVWR:
- 9,050 lbs
- Base Curb Weight:
- 4,982 lbs
- Max Available GCWR:
- 13,930 lbs
- Max Towing:
- 5,000 lbs [1]
- Fuel Tank Capacity:
- 22 gal
Measurements
- Standing Height:
- 65.3 in
- Cargo Bed Length:
- 103.5 in
- Turning Diameter (curb to curb):
- 40.7 ft
- Ground To First Step-Side:
- 20.9 in
- Load height, unloaded (ground to cargo floor):
- 27 in
- Door Opening-Side(Height):
- 59.8 in
- Door Opening-Rear(Height):
- 61 in
- Dual Door Width-Side:
- 49.3 in
- Door Width-Rear:
- 60.7 in
- Max. Cargo Bed Length:
- 103.5 in
- Cargo Width at Wheelhouse:
- 53.1 in
- Max Width at Floor:
- 70.4 in
Powertrain
- Engine:
- 4-Cylinder Gas
- Fuel Type:
- Gas
- Displacement:
- 1,991 cc
- Horsepower:
- 188 hp at 5,000 rpm
- Rated Torque:
- 258 lb-ft at 2,500-3,500 rpm
- Transmission:
- 9G-Tronic
- Drive Shaft:
- RWD
- Emission Certification:
- SULEV
- Injection:
- Bosch direct injection

Crew Van 2500
Dimensions

- Overall Height:
- 96 in
- Overall Length:
- 234 in
- Overall Width with mirrors:
- 92 in
- Wheelbase:
- 144 in
Key Features
- Engine:
- 4-Cylinder Diesel Standard Output
- Payload Capacity:
- 3,825 lbs
- Max Towing:
- 5,000 lbs [1]
- Cargo Volume:
- 240 cu ft
- Standing Height:
- 65 in
- Seating Capacity:
- 5
Capacity
- Seating Capacity:
- 5
- Cargo Volume:
- 240 cu ft
- Max Available GVWR:
- 9,050 lbs
- Max Available GCWR:
- 13,930 lbs
- Max Towing:
- 5,000 lbs [1]
- Fuel Tank Capacity:
- 24.5 gal
- Payload Capacity:
- 3,825 lbs
- Base Curb Weight:
- 5,225 lbs
Measurements
- Standing Height:
- 65 in
- Cargo Bed Length:
- 104 in
- Turning Diameter (curb to curb):
- 45 ft
- Ground To First Step-Side:
- 21 in
- Load height, unloaded (ground to cargo floor):
- 28 in
- Door Opening-Side(Height):
- 60 in
- Door Opening-Rear(Height):
- 61 in
- Dual Door Width-Side:
- 51 in
- Door Width-Rear:
- 61 in
- Max. Cargo Bed Length:
- 104 in
- Cargo Width at Wheelhouse:
- 53 in
- Max Width at Floor:
- 70 in
Powertrain
- Engine:
- 4-Cylinder Diesel Standard Output
- Fuel Type:
- Diesel
- Displacement:
- 1950 cc
- Horsepower:
- 170 hp
- Transmission:
- Automatic Transmission, 9G-TRONIC
- Drive Shaft:
- RWD
- Emission Certification:
- SULEV
- Injection:
- Common-rail direct injection (CDI)
- Rated Torque:
- 295 lb-ft
Dimensions

- Overall Height:
- 96 in
- Overall Length:
- 234 in
- Overall Width with mirrors:
- 92 in
- Wheelbase:
- 144 in
Key Features
- Engine:
- 4-Cylinder Diesel High Output
- Payload Capacity:
- 3,825 lbs
- Max Towing:
- 5,000 lbs [1]
- Cargo Volume:
- 240 cu ft
- Standing Height:
- 65 in
- Seating Capacity:
- 5
Capacity
- Payload Capacity:
- 3,825 lbs
- Seating Capacity:
- 5
- Cargo Volume:
- 240 cu ft
- Max Available GVWR:
- 9,050 lbs
- Base Curb Weight:
- 5,225 lbs
- Max Available GCWR:
- 13,930 lbs
- Max Towing:
- 5,000 lbs [1]
- Fuel Tank Capacity:
- 24.5 gal
Measurements
- Standing Height:
- 65 in
- Cargo Bed Length:
- 104 in
- Turning Diameter (curb to curb):
- 45 ft
- Ground To First Step-Side:
- 21 in
- Load height, unloaded (ground to cargo floor):
- 28 in
- Door Opening-Side(Height):
- 60 in
- Door Opening-Rear(Height):
- 61 in
- Dual Door Width-Side:
- 51 in
- Door Width-Rear:
- 61 in
- Max. Cargo Bed Length:
- 104 in
- Cargo Width at Wheelhouse:
- 53 in
- Max Width at Floor:
- 70 in
Powertrain
- Engine:
- 4-Cylinder Diesel High Output
- Fuel Type:
- Diesel
- Displacement:
- 1950 cc
- Horsepower:
- 211 hp
- Rated Torque:
- 332 lb-ft
- Transmission:
- Automatic Transmission, 9G-TRONIC
- Drive Shaft:
- RWD
- Emission Certification:
- SULEV
- Injection:
- Common-rail direct injection (CDI)

Crew Van 2500
Dimensions

- Overall Height:
- 100 in
- Overall Length:
- 234 in
- Overall Width with mirrors:
- 92 in
- Wheelbase:
- 144 in
Key Features
- Engine:
- 4-Cylinder Diesel High Output AWD
- Payload Capacity:
- 3,472 lbs
- Max Towing:
- 5,000 lbs [1]
- Cargo Volume:
- 223 cu ft
- Standing Height:
- 65 in
- Seating Capacity:
- 5
Capacity
- Payload Capacity:
- 3,472 lbs
- Seating Capacity:
- 5
- Cargo Volume:
- 223 cu ft
- Max Available GVWR:
- 9,050 lbs
- Base Curb Weight:
- 5,578 lbs
- Max Available GCWR:
- 13,930 lbs
- Max Towing:
- 5,000 lbs [1]
- Fuel Tank Capacity:
- 24.5 gal
Measurements
- Standing Height:
- 65 in
- Cargo Bed Length:
- 104 in
- Turning Diameter (curb to curb):
- 43 ft
- Ground To First Step-Side:
- 25 in
- Load height, unloaded (ground to cargo floor):
- 31 in
- Door Opening-Side(Height):
- 60 in
- Door Opening-Rear(Height):
- 61 in
- Dual Door Width-Side:
- 51 in
- Door Width-Rear:
- 61 in
- Max. Cargo Bed Length:
- 104 in
- Cargo Width at Wheelhouse:
- 53 in
- Max Width at Floor:
- 70 in
Powertrain
- Engine:
- 4-Cylinder Diesel High Output AWD
- Fuel Type:
- Diesel
- Displacement:
- 1950 cc
- Horsepower:
- 211 hp
- Rated Torque:
- 332 lb-ft
- Transmission:
- Automatic Transmission, 9G-TRONIC
- Drive Shaft:
- RWD
- Emission Certification:
- SULEV
- Injection:
- Common-rail direct injection (CDI)

Crew Van 3500
Dimensions

- Overall Height:
- 96 in
- Overall Length:
- 234 in
- Overall Width with mirrors:
- 96 in
- Wheelbase:
- 144 in
Key Features
- Engine:
- 4-Cylinder Diesel Standard Output
- Payload Capacity:
- 4,324 lbs
- Max Towing:
- 7,500 lbs [1]
- Cargo Volume:
- 212 cu ft
- Standing Height:
- 65 in
- Seating Capacity:
- 5
Capacity
- Payload Capacity:
- 4,324 lbs
- Seating Capacity:
- 5
- Cargo Volume:
- 212 cu ft
- Max Available GVWR:
- 9,990 lbs
- Base Curb Weight:
- 5,666 lbs
- Max Available GCWR:
- 15,250 lbs
- Max Towing:
- 7,500 lbs [1]
- Fuel Tank Capacity:
- 24.5 gal
Measurements
- Standing Height:
- 65 in
- Cargo Bed Length:
- 104 in
- Turning Diameter (curb to curb):
- 45 ft
- Ground To First Step-Side:
- 22 in
- Door Opening-Side(Height):
- 60 in
- Door Opening-Rear(Height):
- 61 in
- Dual Door Width-Side:
- 51 in
- Door Width-Rear:
- 61 in
- Max. Cargo Bed Length:
- 104 in
- Cargo Width at Wheelhouse:
- 39 in
- Max Width at Floor:
- 70 in
Powertrain
- Engine:
- 4-Cylinder Diesel Standard Output
- Fuel Type:
- Diesel
- Displacement:
- 1,950 cc
- Horsepower:
- 170 hp
- Rated Torque:
- 295 lb-ft
- Transmission:
- Automatic Transmission, 9G-TRONIC
- Drive Shaft:
- RWD
- Emission Certification:
- SULEV
- Injection:
- Common-rail direct injection (CDI)
Dimensions

- Overall Height:
- 96 in
- Overall Length:
- 234 in
- Overall Width with mirrors:
- 96 in
- Wheelbase:
- 144 in
Key Features
- Engine:
- 4-Cylinder Diesel High Output
- Payload Capacity:
- 4,324 lbs
- Max Towing:
- 7,500 lbs [1]
- Cargo Volume:
- 212 cu ft
- Standing Height:
- 65 in
- Seating Capacity:
- 5
Capacity
- Payload Capacity:
- 4,324 lbs
- Seating Capacity:
- 5
- Cargo Volume:
- 212 cu ft
- Max Available GVWR:
- 9,900 lbs
- Base Curb Weight:
- 5,666 lbs
- Max Available GCWR:
- 15,250 lbs
- Max Towing:
- 7,500 lbs [1]
- Fuel Tank Capacity:
- 24.5 gal
Measurements
- Standing Height:
- 65 in
- Cargo Bed Length:
- 104 in
- Turning Diameter (curb to curb):
- 45 ft
- Ground To First Step-Side:
- 22 in
- Door Opening-Side(Height):
- 60 in
- Door Opening-Rear(Height):
- 61 in
- Dual Door Width-Side:
- 51 in
- Door Width-Rear:
- 61 in
- Max. Cargo Bed Length:
- 104 in
- Cargo Width at Wheelhouse:
- 39 in
- Max Width at Floor:
- 70 in
Powertrain
- Engine:
- 4-Cylinder Diesel High Output
- Fuel Type:
- Diesel
- Displacement:
- 1,950 cc
- Horsepower:
- 211 hp
- Rated Torque:
- 332 lb-ft
- Transmission:
- Automatic Transmission, 9G-TRONIC
- Drive Shaft:
- RWD
- Emission Certification:
- SULEV
- Injection:
- Common-rail direct injection (CDI)

Crew Van 3500XD
Dimensions

- Overall Height:
- 98 in
- Overall Length:
- 234 in
- Overall Width with mirrors:
- 96 in
- Wheelbase:
- 144 in
Key Features
- Engine:
- 4-Cylinder Diesel Standard Output
- Payload Capacity:
- 5,375 lbs
- Max Towing:
- 7,500 lbs [1]
- Cargo Volume:
- 212 cu ft
- Standing Height:
- 65 in
- Seating Capacity:
- 5
Capacity
- Payload Capacity:
- 5,375 lbs
- Seating Capacity:
- 5
- Cargo Volume:
- 212 cu ft
- Max Available GVWR:
- 11,030 lbs
- Base Curb Weight:
- 5,655 lbs
- Max Available GCWR:
- 15,250 lbs
- Max Towing:
- 7,500 lbs [1]
- Fuel Tank Capacity:
- 24.5 gal
Measurements
- Standing Height:
- 65 in
- Cargo Bed Length:
- 104 in
- Turning Diameter (curb to curb):
- 45 ft
- Ground To First Step-Side:
- 22 in
- Load height, unloaded (ground to cargo floor):
- 29 in
- Door Opening-Side(Height):
- 60 in
- Door Opening-Rear(Height):
- 61 in
- Dual Door Width-Side:
- 51 in
- Door Width-Rear:
- 61 in
- Max. Cargo Bed Length:
- 104 in
- Cargo Width at Wheelhouse:
- 39 in
- Max Width at Floor:
- 70 in
Powertrain
- Engine:
- 4-Cylinder Diesel Standard Output
- Fuel Type:
- Diesel
- Displacement:
- 1,950 cc
- Horsepower:
- 170 hp
- Rated Torque:
- 295 lb-ft
- Transmission:
- Automatic Transmission, 9G-Tronic
- Drive Shaft:
- RWD
- Emission Certification:
- SULEV
- Injection:
- Common-rail direct injection (CDI)

Crew Van 3500XD
Dimensions

- Overall Height:
- 98 in
- Overall Length:
- 234 in
- Overall Width with mirrors:
- 96 in
- Wheelbase:
- 144 in
Key Features
- Engine:
- 4-Cylinder Diesel High Output
- Payload Capacity:
- 5,375 lbs
- Max Towing:
- 7,500 lbs [1]
- Cargo Volume:
- 212 cu ft
- Standing Height:
- 65 in
- Seating Capacity:
- 5
Capacity
- Payload Capacity:
- 5,375 lbs
- Seating Capacity:
- 5
- Cargo Volume:
- 212 cu ft
- Max Available GVWR:
- 11,030 lbs
- Base Curb Weight:
- 5,655 lbs
- Max Available GCWR:
- 15,250 lbs
- Max Towing:
- 7,500 lbs [1]
- Fuel Tank Capacity:
- 24.5 gal
Measurements
- Standing Height:
- 65 in
- Cargo Bed Length:
- 104 in
- Turning Diameter (curb to curb):
- 45 ft
- Ground To First Step-Side:
- 22 in
- Load height, unloaded (ground to cargo floor):
- 29 in
- Door Opening-Side(Height):
- 60 in
- Door Opening-Rear(Height):
- 61 in
- Dual Door Width-Side:
- 51 in
- Door Width-Rear:
- 61 in
- Max. Cargo Bed Length:
- 104 in
- Cargo Width at Wheelhouse:
- 39 in
- Max Width at Floor:
- 70 in
Powertrain
- Engine:
- 4-Cylinder Diesel High Output
- Fuel Type:
- Diesel
- Displacement:
- 1,950 cc
- Horsepower:
- 211 hp
- Rated Torque:
- 332 lb-ft
- Transmission:
- Automatic Transmission, 9G-TRONIC
- Drive Shaft:
- RWD
- Emission Certification:
- SULEV
- Injection:
- Common-rail direct injection (CDI)

Crew Van 3500XD
Dimensions

- Overall Height:
- 100 in
- Overall Length:
- 234 in
- Overall Width with mirrors:
- 96 in
- Wheelbase:
- 144 in
Key Features
- Engine:
- 4-Cylinder Diesel High Output AWD
- Payload Capacity:
- 5,055 lbs
- Max Towing:
- 7,500 lbs [1]
- Cargo Volume:
- 212 cu ft
- Standing Height:
- 65 in
- Seating Capacity:
- 5
Capacity
- Payload Capacity:
- 5,055 lbs
- Seating Capacity:
- 5
- Cargo Volume:
- 212 cu ft
- Max Available GVWR:
- 11,030 lbs
- Base Curb Weight:
- 5,975 lbs
- Max Available GCWR:
- 15,250 lbs
- Max Towing:
- 7,500 lbs [1]
- Fuel Tank Capacity:
- 24.5 gal
Measurements
- Standing Height:
- 65 in
- Cargo Bed Length:
- 104 in
- Turning Diameter (curb to curb):
- 45 ft
- Ground To First Step-Side:
- 24.8 in
- Load height, unloaded (ground to cargo floor):
- 31 in
- Door Opening-Side(Height):
- 60 in
- Door Opening-Rear(Height):
- 61 in
- Dual Door Width-Side:
- 51 in
- Door Width-Rear:
- 61 in
- Max. Cargo Bed Length:
- 104 in
- Cargo Width at Wheelhouse:
- 39 in
- Max Width at Floor:
- 70 in
Powertrain
- Engine:
- 4-Cylinder Diesel High Output AWD
- Fuel Type:
- Diesel
- Displacement:
- 1,950 cc
- Horsepower:
- 211 hp
- Rated Torque:
- 332 lb-ft
- Transmission:
- Automatic Transmission, 9G-TRONIC
- Drive Shaft:
- RWD
- Emission Certification:
- SULEV
- Injection:
- Common-rail direct injection (CDI)

Crew Van 4500
Dimensions

- Overall Height:
- 98 in
- Overall Length:
- 234 in
- Overall Width with mirrors:
- 96 in
- Wheelbase:
- 144 in
Key Features
- Engine:
- 4-Cylinder Diesel Standard Output
- Payload Capacity:
- 6,437 lbs
- Max Towing:
- 7,500 lbs [1]
- Cargo Volume:
- 212 cu ft
- Standing Height:
- 65 in
- Seating Capacity:
- 5
Capacity
- Payload Capacity:
- 6,437 lbs
- Seating Capacity:
- 5
- Cargo Volume:
- 212 cu ft
- Max Available GVWR:
- 12,125 lbs
- Base Curb Weight:
- 5,688 lbs
- Max Available GCWR:
- 15,250 lbs
- Max Towing:
- 7,500 lbs [1]
- Fuel Tank Capacity:
- 24.5 gal
Measurements
- Standing Height:
- 65 in
- Cargo Bed Length:
- 104 in
- Turning Diameter (curb to curb):
- 45 ft
- Ground To First Step-Side:
- 22 in
- Load height, unloaded (ground to cargo floor):
- 29 in
- Door Opening-Side(Height):
- 60 in
- Door Opening-Rear(Height):
- 61 in
- Dual Door Width-Side:
- 51 in
- Door Width-Rear:
- 61 in
- Max. Cargo Bed Length:
- 104 in
- Cargo Width at Wheelhouse:
- 39 in
- Max Width at Floor:
- 70 in
Powertrain
- Engine:
- 4-Cylinder Diesel Standard Output
- Fuel Type:
- Diesel
- Displacement:
- 1.,950 cc
- Horsepower:
- 170 hp
- Rated Torque:
- 332 lb-ft
- Transmission:
- Automatic Transmission,9G-TRONIC
- Drive Shaft:
- RWD
- Emission Certification:
- SULEV
- Injection:
- Common-rail direct injection (CDI)
Dimensions

- Overall Height:
- 98 in
- Overall Length:
- 234 in
- Overall Width with mirrors:
- 96 in
- Wheelbase:
- 144 in
Key Features
- Engine:
- 4-Cylinder Diesel High Output
- Payload Capacity:
- 6,437 lbs
- Max Towing:
- 7,500 lbs [1]
- Cargo Volume:
- 212 cu ft
- Standing Height:
- 65 in
- Seating Capacity:
- 5
Capacity
- Payload Capacity:
- 6,437 lbs
- Seating Capacity:
- 5
- Cargo Volume:
- 212 cu ft
- Max Available GVWR:
- 12,125 lbs
- Base Curb Weight:
- 5,688 lbs
- Max Available GCWR:
- 15,250 lbs
- Max Towing:
- 7,500 lbs [1]
- Fuel Tank Capacity:
- 24.5 gal
Measurements
- Standing Height:
- 65 in
- Cargo Bed Length:
- 104 in
- Turning Diameter (curb to curb):
- 45 ft
- Ground To First Step-Side:
- 22 in
- Load height, unloaded (ground to cargo floor):
- 29 in
- Door Opening-Side(Height):
- 60 in
- Door Opening-Rear(Height):
- 61 in
- Dual Door Width-Side:
- 51 in
- Door Width-Rear:
- 61 in
- Max. Cargo Bed Length:
- 104 in
- Cargo Width at Wheelhouse:
- 39 in
- Max Width at Floor:
- 70 in
Powertrain
- Engine:
- 4-Cylinder Diesel High Output
- Fuel Type:
- Diesel
- Displacement:
- 1,950 cc
- Horsepower:
- 211 hp
- Rated Torque:
- 332 lb-ft
- Transmission:
- Automatic Transmission,9G_TRONIC
- Drive Shaft:
- RWD
- Emission Certification:
- SULEV
- Injection:
- Common-rail direct injection (CDI)
2023
Dimensions

- Overall Height:
- 107.5 in
- Overall Length:
- 233.5 in
- Overall Width with mirrors:
- 92.3 in
- Wheelbase:
- 144 in
Key Features
- Engine:
- 4-Cylinder Gas
- Payload Capacity:
- 3,979 lbs
- Max Towing:
- 5,000 lbs [1]
- Cargo Volume:
- 261.3 cu ft
- Standing Height:
- 76.7 in
- Seating Capacity:
- 5
Capacity
- Payload Capacity:
- 3,979 lbs
- Seating Capacity:
- 5
- Cargo Volume:
- 261.3 cu ft
- Max Available GVWR:
- 9,050 lbs
- Base Curb Weight:
- 5,071 lbs
- Max Available GCWR:
- 13,930 lbs
- Max Towing:
- 5,000 lbs [1]
- Fuel Tank Capacity:
- 22 gal
Measurements
- Standing Height:
- 76.7 in
- Cargo Bed Length:
- 103.5 in
- Turning Diameter (curb to curb):
- 40.7 ft
- Ground To First Step-Side:
- 20.8 in
- Load height, unloaded (ground to cargo floor):
- 27 in
- Door Opening-Side(Height):
- 71.6 in
- Door Opening-Rear(Height):
- 72.7 in
- Dual Door Width-Side:
- 51 in
- Door Width-Rear:
- 61.2 in
- Max. Cargo Bed Length:
- 103.5 in
- Cargo Width at Wheelhouse:
- 53.1 in
- Max Width at Floor:
- 70.4 in
Powertrain
- Engine:
- 4-Cylinder Gas
- Fuel Type:
- Gas
- Displacement:
- 1,991 cc
- Horsepower:
- 188 hp at 5,000 rpm
- Rated Torque:
- 258 lb-ft at 2,500-3,500 rpm
- Transmission:
- 9G-Tronic
- Drive Shaft:
- RWD
- Emission Certification:
- SULEV
- Injection:
- Bosch direct injection

Crew Van 2500
Dimensions

- Overall Height:
- 108 in
- Overall Length:
- 234 in
- Overall Width with mirrors:
- 92 in
- Wheelbase:
- 144 in
Key Features
- Engine:
- 4-Cylinder Diesel Standard Output
- Payload Capacity:
- 3,737 lbs
- Max Towing:
- 5,000 lbs [1]
- Cargo Volume:
- 279 cu ft
- Standing Height:
- 77 in
- Seating Capacity:
- 5
Capacity
- Seating Capacity:
- 5
- Cargo Volume:
- 279 cu ft
- Max Available GVWR:
- 9,050 lbs
- Max Available GCWR:
- 13,930 lbs
- Max Towing:
- 5,000 lbs [1]
- Fuel Tank Capacity:
- 24.5 gal
- Payload Capacity:
- 3,737 lbs
- Base Curb Weight:
- 5,313 lbs
Measurements
- Standing Height:
- 77 in
- Cargo Bed Length:
- 104 in
- Turning Diameter (curb to curb):
- 45 ft
- Ground To First Step-Side:
- 21 in
- Load height, unloaded (ground to cargo floor):
- 28 in
- Door Opening-Side(Height):
- 72 in
- Door Opening-Rear(Height):
- 73 in
- Dual Door Width-Side:
- 51 in
- Door Width-Rear:
- 61 in
- Max. Cargo Bed Length:
- 104 in
- Cargo Width at Wheelhouse:
- 53 in
- Max Width at Floor:
- 70 in
Powertrain
- Engine:
- 4-Cylinder Diesel Standard Output
- Fuel Type:
- Diesel
- Displacement:
- 1950 cc
- Horsepower:
- 170 hp
- Transmission:
- Automatic Transmission, 9G-TRONIC
- Drive Shaft:
- RWD
- Emission Certification:
- SULEV
- Injection:
- Common-rail direct injection (CDI)
- Rated Torque:
- 295 lb-ft
Dimensions

- Overall Height:
- 108 in
- Overall Length:
- 234 in
- Overall Width with mirrors:
- 92 in
- Wheelbase:
- 144 in
Key Features
- Engine:
- 4-Cylinder Diesel High Output
- Payload Capacity:
- 3,737 lbs
- Max Towing:
- 5,000 lbs [1]
- Cargo Volume:
- 279 cu ft
- Standing Height:
- 77 in
- Seating Capacity:
- 5
Capacity
- Payload Capacity:
- 3,737 lbs
- Seating Capacity:
- 5
- Cargo Volume:
- 279 cu ft
- Max Available GVWR:
- 9,050 lbs
- Base Curb Weight:
- 5,313 lbs
- Max Available GCWR:
- 13,930 lbs
- Max Towing:
- 5,000 lbs [1]
- Fuel Tank Capacity:
- 24.5 gal
Measurements
- Standing Height:
- 77 in
- Cargo Bed Length:
- 104 in
- Turning Diameter (curb to curb):
- 45 ft
- Ground To First Step-Side:
- 21 in
- Load height, unloaded (ground to cargo floor):
- 28 in
- Door Opening-Side(Height):
- 72 in
- Door Opening-Rear(Height):
- 73 in
- Dual Door Width-Side:
- 51 in
- Door Width-Rear:
- 61 in
- Max. Cargo Bed Length:
- 104 in
- Cargo Width at Wheelhouse:
- 53 in
- Max Width at Floor:
- 70 in
Powertrain
- Engine:
- 4-Cylinder Diesel High Output
- Fuel Type:
- Diesel
- Displacement:
- 1950 cc
- Horsepower:
- 211 hp
- Rated Torque:
- 332 lb-ft
- Transmission:
- Automatic Transmission, 9G-TRONIC
- Drive Shaft:
- RWD
- Emission Certification:
- SULEV
- Injection:
- Common-rail direct injection (CDI)

Crew Van 2500
Dimensions

- Overall Height:
- 111 in
- Overall Length:
- 234 in
- Overall Width with mirrors:
- 92 in
- Wheelbase:
- 144 in
Key Features
- Engine:
- 4-Cylinder Diesel High output AWD
- Payload Capacity:
- 3,384 lbs
- Max Towing:
- 5,000 lbs [1]
- Cargo Volume:
- 279 cu ft
- Standing Height:
- 77 in
- Seating Capacity:
- 5
Capacity
- Payload Capacity:
- 3,384 lbs
- Seating Capacity:
- 5
- Cargo Volume:
- 279 cu ft
- Max Available GVWR:
- 9,050 lbs
- Base Curb Weight:
- 5,666 lbs
- Max Available GCWR:
- 13,930 lbs
- Max Towing:
- 5,000 lbs [1]
- Fuel Tank Capacity:
- 24.5 gal
Measurements
- Standing Height:
- 77 in
- Cargo Bed Length:
- 104 in
- Turning Diameter (curb to curb):
- 45 ft
- Ground To First Step-Side:
- 25 in
- Load height, unloaded (ground to cargo floor):
- 31 in
- Door Opening-Side(Height):
- 72 in
- Door Opening-Rear(Height):
- 73 in
- Dual Door Width-Side:
- 51 in
- Door Width-Rear:
- 61 in
- Max. Cargo Bed Length:
- 104 in
- Cargo Width at Wheelhouse:
- 53 in
- Max Width at Floor:
- 70 in
Powertrain
- Engine:
- 4-Cylinder Diesel High output AWD
- Fuel Type:
- Diesel
- Displacement:
- 1950 cc
- Horsepower:
- 211 hp
- Rated Torque:
- 332 lb-ft
- Transmission:
- Automatic Transmission, 9G-TRONIC
- Drive Shaft:
- RWD
- Emission Certification:
- SULEV
- Injection:
- Common-rail direct injection (CDI)

Crew Van 3500
Dimensions

- Overall Height:
- 109 in
- Overall Length:
- 234 in
- Overall Width with mirrors:
- 96 in
- Wheelbase:
- 144 in
Key Features
- Engine:
- 4-Cylinder Diesel High Output
- Payload Capacity:
- 4,236 lbs
- Max Towing:
- 7,500 lbs [1]
- Cargo Volume:
- 247 cu ft
- Standing Height:
- 77 in
- Seating Capacity:
- 5
Capacity
- Payload Capacity:
- 4,236 lbs
- Seating Capacity:
- 5
- Cargo Volume:
- 247 cu ft
- Max Available GVWR:
- 9,990 lbs
- Base Curb Weight:
- 5,754 lbs
- Max Available GCWR:
- 15,250 lbs
- Max Towing:
- 7,500 lbs [1]
- Fuel Tank Capacity:
- 24.5 gal
Measurements
- Standing Height:
- 77 in
- Cargo Bed Length:
- 104 in
- Turning Diameter (curb to curb):
- 45 ft
- Ground To First Step-Side:
- 22 in
- Door Opening-Side(Height):
- 72 in
- Door Opening-Rear(Height):
- 73 in
- Dual Door Width-Side:
- 51 in
- Door Width-Rear:
- 61 in
- Max. Cargo Bed Length:
- 104 in
- Cargo Width at Wheelhouse:
- 39 in
- Max Width at Floor:
- 70 in
Powertrain
- Engine:
- 4-Cylinder Diesel High Output
- Fuel Type:
- Diesel
- Displacement:
- 1950 cc
- Horsepower:
- 170 hp
- Rated Torque:
- 332 lb-ft
- Transmission:
- Automatic Transmission, 9G-TRONIC
- Drive Shaft:
- RWD
- Emission Certification:
- SULEV
- Injection:
- Common-rail direct injection (CDI)
Dimensions

- Overall Height:
- 109 in
- Overall Length:
- 234 in
- Overall Width with mirrors:
- 96 in
- Wheelbase:
- 144 in
Key Features
- Engine:
- 4-Cylinder Diesel High Output
- Payload Capacity:
- 4,236 lbs
- Max Towing:
- 7,500 lbs [1]
- Cargo Volume:
- 247 cu ft
- Standing Height:
- 77 in
- Seating Capacity:
- 5
Capacity
- Payload Capacity:
- 4,236 lbs
- Seating Capacity:
- 5
- Cargo Volume:
- 247 cu ft
- Max Available GVWR:
- 9,050 lbs
- Base Curb Weight:
- 5,754 lbs
- Max Available GCWR:
- 15,250 lbs
- Max Towing:
- 7,500 lbs [1]
- Fuel Tank Capacity:
- 24.5 gal
Measurements
- Standing Height:
- 77 in
- Cargo Bed Length:
- 104 in
- Turning Diameter (curb to curb):
- 45 ft
- Ground To First Step-Side:
- 22 in
- Load height, unloaded (ground to cargo floor):
- 29 in
- Door Opening-Side(Height):
- 72 in
- Door Opening-Rear(Height):
- 73 in
- Dual Door Width-Side:
- 51 in
- Door Width-Rear:
- 61 in
- Max. Cargo Bed Length:
- 104 in
- Cargo Width at Wheelhouse:
- 39 in
- Max Width at Floor:
- 70 in
Powertrain
- Engine:
- 4-Cylinder Diesel High Output
- Fuel Type:
- Diesel
- Displacement:
- 1,950 cc
- Horsepower:
- 211 hp
- Rated Torque:
- 332 lb-ft
- Transmission:
- Automatic Transmission,9G-TRONIC
- Drive Shaft:
- RWD
- Emission Certification:
- SULEV
- Injection:
- Common-rail direct injection (CDI)

Crew Van 3500XD
Dimensions

- Overall Height:
- 109 in
- Overall Length:
- 234 in
- Overall Width with mirrors:
- 96 in
- Wheelbase:
- 144 in
Key Features
- Engine:
- 4-Cylinder Diesel Standard Output
- Payload Capacity:
- 5,287 lbs
- Max Towing:
- 7,500 lbs [1]
- Cargo Volume:
- 247 cu ft
- Standing Height:
- 77 in
- Seating Capacity:
- 5
Capacity
- Payload Capacity:
- 5,287 lbs
- Seating Capacity:
- 5
- Cargo Volume:
- 247 cu ft
- Max Available GVWR:
- 11,030 lbs
- Base Curb Weight:
- 5,743 lbs
- Max Available GCWR:
- 15,250 lbs
- Max Towing:
- 7,500 lbs [1]
- Fuel Tank Capacity:
- 24.5 gal
Measurements
- Standing Height:
- 77 in
- Cargo Bed Length:
- 104 in
- Turning Diameter (curb to curb):
- 45 ft
- Ground To First Step-Side:
- 22 in
- Load height, unloaded (ground to cargo floor):
- 29 in
- Door Opening-Side(Height):
- 72 in
- Door Opening-Rear(Height):
- 73 in
- Dual Door Width-Side:
- 51 in
- Door Width-Rear:
- 61 in
- Max. Cargo Bed Length:
- 104 in
- Cargo Width at Wheelhouse:
- 39 in
- Max Width at Floor:
- 70 in
Powertrain
- Engine:
- 4-Cylinder Diesel Standard Output
- Fuel Type:
- Diesel
- Displacement:
- 1,950 cc
- Horsepower:
- 170 hp
- Rated Torque:
- 295 lb-ft
- Transmission:
- Automatic Transmission,9G-TRONIC
- Drive Shaft:
- RWD
- Emission Certification:
- SULEV
- Injection:
- Common-rail direct injection (CDI)

Crew Van 3500XD
Dimensions

- Overall Height:
- 109 in
- Overall Length:
- 234 in
- Overall Width with mirrors:
- 96 in
- Wheelbase:
- 144 in
Key Features
- Engine:
- 4-Cylinder Diesel High Output
- Payload Capacity:
- 5,287 lbs
- Max Towing:
- 7,500 lbs [1]
- Cargo Volume:
- 247 cu ft
- Standing Height:
- 77 in
- Seating Capacity:
- 5
Capacity
- Payload Capacity:
- 5,287 lbs
- Seating Capacity:
- 5
- Cargo Volume:
- 247 cu ft
- Max Available GVWR:
- 11,030 lbs
- Base Curb Weight:
- 5,743 lbs
- Max Available GCWR:
- 15,250 lbs
- Max Towing:
- 7,500 lbs [1]
- Fuel Tank Capacity:
- 24.5 gal
Measurements
- Standing Height:
- 77 in
- Cargo Bed Length:
- 104 in
- Turning Diameter (curb to curb):
- 45 ft
- Ground To First Step-Side:
- 22 in
- Load height, unloaded (ground to cargo floor):
- 29 in
- Door Opening-Side(Height):
- 72 in
- Door Opening-Rear(Height):
- 73 in
- Dual Door Width-Side:
- 51.0 in
- Door Width-Rear:
- 61 in
- Max. Cargo Bed Length:
- 104 in
- Cargo Width at Wheelhouse:
- 39 in
- Max Width at Floor:
- 70 in
Powertrain
- Engine:
- 4-Cylinder Diesel High Output
- Fuel Type:
- Diesel
- Displacement:
- 1,950 cc
- Horsepower:
- 211 hp
- Rated Torque:
- 332 lb-ft
- Transmission:
- Automatic Transmission, 9G-TRONIC
- Drive Shaft:
- RWD
- Emission Certification:
- SULEV
- Injection:
- Common-rail direct injection (CDI)

Crew Van 3500XD
Dimensions

- Overall Height:
- 111 in
- Overall Length:
- 234 in
- Overall Width with mirrors:
- 92 in
- Wheelbase:
- 144 in
Key Features
- Engine:
- 4-Cylinder Diesel High Output AWD
- Payload Capacity:
- 4,967 lbs
- Max Towing:
- 7,500 lbs [1]
- Cargo Volume:
- 247 cu ft
- Standing Height:
- 77 in
- Seating Capacity:
- 5
Capacity
- Payload Capacity:
- 4,967 lbs
- Seating Capacity:
- 5
- Cargo Volume:
- 247 cu ft
- Max Available GVWR:
- 11,030 lbs
- Base Curb Weight:
- 6.063 lbs
- Max Available GCWR:
- 15,250 lbs
- Max Towing:
- 7,500 lbs [1]
- Fuel Tank Capacity:
- 24.5 gal
Measurements
- Standing Height:
- 77 in
- Cargo Bed Length:
- 104 in
- Turning Diameter (curb to curb):
- 45 ft
- Ground To First Step-Side:
- 21 in
- Load height, unloaded (ground to cargo floor):
- 31 in
- Door Opening-Side(Height):
- 72 in
- Door Opening-Rear(Height):
- 73 in
- Dual Door Width-Side:
- 51 in
- Door Width-Rear:
- 61 in
- Max. Cargo Bed Length:
- 104 in
- Cargo Width at Wheelhouse:
- 39 in
- Max Width at Floor:
- 70 in
Powertrain
- Engine:
- 4-Cylinder Diesel High Output AWD
- Fuel Type:
- Diesel
- Displacement:
- 1,950 cc
- Horsepower:
- 211 hp
- Rated Torque:
- 332 lb-ft
- Transmission:
- Automatic Transmission,9G-TRONIC
- Drive Shaft:
- RWD
- Emission Certification:
- SULEV
- Injection:
- Common-rail direct injection (CDI)

Crew Van 4500
Dimensions

- Overall Height:
- 109 in
- Overall Length:
- 234 in
- Overall Width with mirrors:
- 96 in
- Wheelbase:
- 144 in
Key Features
- Engine:
- 4-Cylinder Diesel Standard Output
- Payload Capacity:
- 6,349 lbs
- Max Towing:
- 7,500 lbs [1]
- Cargo Volume:
- 247 cu ft
- Standing Height:
- 77 in
- Seating Capacity:
- 5
Capacity
- Payload Capacity:
- 6,349 lbs
- Seating Capacity:
- 5
- Cargo Volume:
- 247 cu ft
- Max Available GVWR:
- 12,125 lbs
- Base Curb Weight:
- 6,349 lbs
- Max Available GCWR:
- 15,250 lbs
- Max Towing:
- 7,500 lbs [1]
- Fuel Tank Capacity:
- 24.5 gal
Measurements
- Standing Height:
- 77 in
- Cargo Bed Length:
- 104 in
- Turning Diameter (curb to curb):
- 45 ft
- Ground To First Step-Side:
- 21 in
- Load height, unloaded (ground to cargo floor):
- 29 in
- Door Opening-Side(Height):
- 72 in
- Door Opening-Rear(Height):
- 73 in
- Dual Door Width-Side:
- 51 in
- Door Width-Rear:
- 61 in
- Max. Cargo Bed Length:
- 104 in
- Cargo Width at Wheelhouse:
- 39 in
- Max Width at Floor:
- 70 in
Powertrain
- Engine:
- 4-Cylinder Diesel Standard Output
- Fuel Type:
- Diesel
- Displacement:
- 1,950 cc
- Horsepower:
- 170 hp
- Rated Torque:
- 295 lb-ft
- Transmission:
- Automatic Transmission,9G-TRONIC
- Drive Shaft:
- RWD
- Emission Certification:
- SULEV
- Injection:
- Common-rail direct injection (CDI)
Dimensions

- Overall Height:
- 109 in
- Overall Length:
- 234 in
- Overall Width with mirrors:
- 96 in
- Wheelbase:
- 144 in
Key Features
- Engine:
- 4-Cylinder Diesel High Output
- Payload Capacity:
- 6,349 lbs
- Max Towing:
- 7,500 lbs [1]
- Cargo Volume:
- 247 cu ft
- Standing Height:
- 77 in
- Seating Capacity:
- 5
Capacity
- Payload Capacity:
- 6,349 lbs
- Seating Capacity:
- 5
- Cargo Volume:
- 247 cu ft
- Max Available GVWR:
- 12,125 lbs
- Base Curb Weight:
- 5,776 lbs
- Max Available GCWR:
- 15,250 lbs
- Max Towing:
- 7,500 lbs [1]
- Fuel Tank Capacity:
- 24.5 gal
Measurements
- Standing Height:
- 77 in
- Cargo Bed Length:
- 104 in
- Turning Diameter (curb to curb):
- 45 ft
- Ground To First Step-Side:
- 21 in
- Load height, unloaded (ground to cargo floor):
- 29 in
- Door Opening-Side(Height):
- 72 in
- Door Opening-Rear(Height):
- 73 in
- Dual Door Width-Side:
- 51 in
- Door Width-Rear:
- 61 in
- Max. Cargo Bed Length:
- 104 in
- Cargo Width at Wheelhouse:
- 39 in
- Max Width at Floor:
- 70 in
Powertrain
- Engine:
- 4-Cylinder Diesel High Output
- Fuel Type:
- Diesel
- Displacement:
- 1,950 cc
- Horsepower:
- 211 hp
- Rated Torque:
- 332 lb-ft
- Transmission:
- Automatic Transmission, 9G-TRONIC
- Drive Shaft:
- RWD
- Emission Certification:
- SULEV
- Injection:
- Common-rail direct injection (CDI)
2023
Dimensions

- Overall Height:
- 107.3 in
- Overall Length:
- 274.3 in
- Overall Width with mirrors:
- 92.3 in
- Wheelbase:
- 170 in
Key Features
- Engine:
- 4-Cylinder Gas
- Payload Capacity:
- 3,627 lbs
- Max Towing:
- 5,000 lbs [1]
- Cargo Volume:
- 370.8 cu ft
- Standing Height:
- 76.7
- Seating Capacity:
- 5
Capacity
- Payload Capacity:
- 3,627 lbs
- Seating Capacity:
- 5
- Cargo Volume:
- 370.8 cu ft
- Max Available GVWR:
- 9,050 lbs
- Base Curb Weight:
- 5,423 lbs
- Max Available GCWR:
- 13,930 lbs
- Max Towing:
- 5,000 lbs [1]
- Fuel Tank Capacity:
- 22 gal
Measurements
- Standing Height:
- 76.7
- Cargo Bed Length:
- 144.3
- Turning Diameter (curb to curb):
- 47.2 ft
- Ground To First Step-Side:
- 20.4 in
- Load height, unloaded (ground to cargo floor):
- 27 in
- Door Opening-Side(Height):
- 71.6 in
- Door Opening-Rear(Height):
- 72.7 in
- Dual Door Width-Side:
- 51 in
- Door Width-Rear:
- 61.2 in
- Max. Cargo Bed Length:
- 144.3 in
- Cargo Width at Wheelhouse:
- 53.1 in
- Max Width at Floor:
- 70.4 in
Powertrain
- Engine:
- 4-Cylinder Gas
- Fuel Type:
- Gas
- Displacement:
- 1,991 cc
- Horsepower:
- 188 hp at 5,000 rpm
- Rated Torque:
- 258 lb-ft at 2,500-3,500 rpm
- Transmission:
- 9G-Tronic
- Drive Shaft:
- RWD
- Emission Certification:
- SULEV
- Injection:
- Bosch direct injection

Crew Van 2500
Dimensions

- Overall Height:
- 107 in
- Overall Length:
- 274 in
- Overall Width with mirrors:
- 92 in
- Wheelbase:
- 170 in
Key Features
- Engine:
- 4-Cylinder Diesel Standard Output
- Payload Capacity:
- 3,384 lbs
- Max Towing:
- 5,000 lbs [1]
- Cargo Volume:
- 396 cu ft
- Standing Height:
- 77 in
- Seating Capacity:
- 2-3
Capacity
- Payload Capacity:
- 3,384 lbs
- Seating Capacity:
- 2-3
- Cargo Volume:
- 396 cu ft
- Max Available GVWR:
- 9,050 lbs
- Base Curb Weight:
- 5,666 lbs
- Max Available GCWR:
- 13,930 lbs
- Max Towing:
- 5,000 lbs [1]
- Fuel Tank Capacity:
- 22 gal
Measurements
- Standing Height:
- 77 in
- Cargo Bed Length:
- 144 in
- Turning Diameter (curb to curb):
- 52 ft
- Ground To First Step-Side:
- 20 in
- Load height, unloaded (ground to cargo floor):
- 27 in
- Door Opening-Side(Height):
- 72 in
- Door Opening-Rear(Height):
- 73 in
- Dual Door Width-Side:
- 51 in
- Door Width-Rear:
- 61 in
- Max. Cargo Bed Length:
- 144 in
- Cargo Width at Wheelhouse:
- 53 in
- Max Width at Floor:
- 70 in
Powertrain
- Engine:
- 4-Cylinder Diesel Standard Output
- Fuel Type:
- Diesel
- Displacement:
- 1,950 cc
- Horsepower:
- 170 hp
- Rated Torque:
- 295 lb-ft
- Transmission:
- Automatic Transmission, 9G-TRONIC
- Drive Shaft:
- RWD
- Emission Certification:
- SULEV
- Injection:
- Common-rail direct injection (CDI)
Dimensions

- Overall Height:
- 107 in
- Overall Length:
- 274 in
- Overall Width with mirrors:
- 92 in
- Wheelbase:
- 170 in
Key Features
- Engine:
- 4-Cylinder Diesel High Output
- Payload Capacity:
- 3,384 lbs
- Max Towing:
- 5,000 lbs [1]
- Cargo Volume:
- 396 cu ft
- Standing Height:
- 77 in
- Seating Capacity:
- 5
Capacity
- Payload Capacity:
- 3,384 lbs
- Seating Capacity:
- 5
- Cargo Volume:
- 396 cu ft
- Max Available GVWR:
- 9,050 lbs
- Base Curb Weight:
- 5,666 lbs
- Max Available GCWR:
- 13,930 lbs
- Max Towing:
- 5,000 lbs [1]
- Fuel Tank Capacity:
- 24.5 gal
Measurements
- Standing Height:
- 77 in
- Cargo Bed Length:
- 144 in
- Turning Diameter (curb to curb):
- 52 ft
- Ground To First Step-Side:
- 20 in
- Load height, unloaded (ground to cargo floor):
- 27 in
- Door Opening-Side(Height):
- 72 in
- Door Opening-Rear(Height):
- 73 in
- Dual Door Width-Side:
- 51 in
- Door Width-Rear:
- 61 in
- Max. Cargo Bed Length:
- 144 in
- Cargo Width at Wheelhouse:
- 53 in
- Max Width at Floor:
- 70 in
Powertrain
- Engine:
- 4-Cylinder Diesel High Output
- Fuel Type:
- Diesel
- Displacement:
- 1,950 cc
- Horsepower:
- 211 hp
- Rated Torque:
- 332 lb-ft
- Transmission:
- Automatic Transmission, 9G-TRONIC
- Drive Shaft:
- RWD
- Emission Certification:
- SULEV
- Injection:
- Common-rail direct injection (CDI)

Crew Van 2500
Dimensions

- Overall Height:
- 111 in
- Overall Length:
- 274 in
- Overall Width with mirrors:
- 92 in
- Wheelbase:
- 170 in
Key Features
- Engine:
- 4-Cylinder Diesel High output AWD
- Payload Capacity:
- 3,031 lbs
- Max Towing:
- 5,000 lbs [1]
- Cargo Volume:
- 396 cu ft
- Standing Height:
- 111 in
- Seating Capacity:
- 5
Capacity
- Payload Capacity:
- 3,031 lbs
- Seating Capacity:
- 5
- Cargo Volume:
- 396 cu ft
- Max Available GVWR:
- 9,050 lbs
- Base Curb Weight:
- 6,019 lbs
- Max Available GCWR:
- 13,930 lbs
- Max Towing:
- 5,000 lbs [1]
- Fuel Tank Capacity:
- 24.5 gal
Measurements
- Standing Height:
- 111 in
- Cargo Bed Length:
- 144 in
- Turning Diameter (curb to curb):
- 52 ft
- Ground To First Step-Side:
- 24 in
- Load height, unloaded (ground to cargo floor):
- 31 in
- Door Opening-Side(Height):
- 72 in
- Door Opening-Rear(Height):
- 73 in
- Dual Door Width-Side:
- 51 in
- Door Width-Rear:
- 61 in
- Max. Cargo Bed Length:
- 144 in
- Cargo Width at Wheelhouse:
- 53 in
- Max Width at Floor:
- 70 in
Powertrain
- Engine:
- 4-Cylinder Diesel High output AWD
- Fuel Type:
- Diesel
- Displacement:
- 1,950 cc
- Horsepower:
- 211 hp
- Rated Torque:
- 332 lb-ft
- Transmission:
- Automatic Transmission, 9G-TRONIC
- Drive Shaft:
- RWD
- Emission Certification:
- SULEV
- Injection:
- Common-rail direct injection (CDI)

Crew Van 3500
Dimensions

- Overall Height:
- 109 in
- Overall Length:
- 274 in
- Overall Width with mirrors:
- 96 in
- Wheelbase:
- 170 in
Key Features
- Engine:
- 4-Cylinder Diesel Standard output
- Payload Capacity:
- 3,850 lbs
- Max Towing:
- 7,500 lbs [1]
- Cargo Volume:
- 350 cu ft
- Standing Height:
- 77 in
- Seating Capacity:
- 5
Capacity
- Payload Capacity:
- 3,850 lbs
- Seating Capacity:
- 5
- Cargo Volume:
- 350 cu ft
- Max Available GVWR:
- 9,990 lbs
- Base Curb Weight:
- 6,140 lbs
- Max Available GCWR:
- 15,250 lbs
- Max Towing:
- 7,500 lbs [1]
- Fuel Tank Capacity:
- 24.5 gal
Measurements
- Standing Height:
- 77 in
- Cargo Bed Length:
- 144 in
- Turning Diameter (curb to curb):
- 52 ft
- Ground To First Step-Side:
- 21 in
- Load height, unloaded (ground to cargo floor):
- 29 in
- Door Opening-Side(Height):
- 72 in
- Door Opening-Rear(Height):
- 73 in
- Dual Door Width-Side:
- 51 in
- Door Width-Rear:
- 61 in
- Max. Cargo Bed Length:
- 144 in
- Cargo Width at Wheelhouse:
- 39 in
- Max Width at Floor:
- 70 in
Powertrain
- Engine:
- 4-Cylinder Diesel Standard output
- Fuel Type:
- Diesel
- Displacement:
- 1,950 cc
- Horsepower:
- 170 hp
- Rated Torque:
- 295 lb-ft
- Transmission:
- Automatic Transmission,9G-TRONIC
- Drive Shaft:
- RWD
- Emission Certification:
- SULEV
- Injection:
- Common-rail direct injection (CDI)
Dimensions

- Overall Height:
- 109 in
- Overall Length:
- 274 in
- Overall Width with mirrors:
- 92.3 in
- Wheelbase:
- 170 in
Key Features
- Engine:
- 4-Cylinder Diesel High Output
- Payload Capacity:
- 3,850 lbs
- Max Towing:
- 7,500 lbs [1]
- Cargo Volume:
- 371 cu ft
- Standing Height:
- 77 in
- Seating Capacity:
- 5
Capacity
- Payload Capacity:
- 3,850 lbs
- Seating Capacity:
- 5
- Cargo Volume:
- 371 cu ft
- Max Available GVWR:
- 9,990 lbs
- Base Curb Weight:
- 6,217 lbs
- Max Available GCWR:
- 15,250 lbs
- Max Towing:
- 7,500 lbs [1]
- Fuel Tank Capacity:
- 24.5 gal
Measurements
- Standing Height:
- 77 in
- Cargo Bed Length:
- 144 in
- Turning Diameter (curb to curb):
- 53 ft
- Ground To First Step-Side:
- 21 in
- Load height, unloaded (ground to cargo floor):
- 28 in
- Door Opening-Side(Height):
- 72 in
- Door Opening-Rear(Height):
- 73 in
- Dual Door Width-Side:
- 51 in
- Door Width-Rear:
- 61 in
- Max. Cargo Bed Length:
- 144 in
- Cargo Width at Wheelhouse:
- 39 in
- Max Width at Floor:
- 70 in
Powertrain
- Engine:
- 4-Cylinder Diesel High Output
- Fuel Type:
- Diesel
- Displacement:
- 1,950 cc
- Horsepower:
- 211 hp
- Rated Torque:
- 332 lb-ft
- Transmission:
- Automatic Transmission,9G-TRONIC
- Drive Shaft:
- RWD
- Emission Certification:
- SULEV
- Injection:
- Common-rail direct injection (CDI)

Crew Van 3500XD
Dimensions

- Overall Height:
- 107 in
- Overall Length:
- 274 in
- Overall Width with mirrors:
- 92 in
- Wheelbase:
- 170 in
Key Features
- Engine:
- 4-Cylinder Diesel Standard Output
- Payload Capacity:
- 4,901 lbs
- Max Towing:
- 7,500 lbs [1]
- Cargo Volume:
- 350 cu ft
- Standing Height:
- 77 in
- Seating Capacity:
- 5
Capacity
- Payload Capacity:
- 4,901 lbs
- Seating Capacity:
- 5
- Cargo Volume:
- 350 cu ft
- Max Available GVWR:
- 11,030 lbs
- Base Curb Weight:
- 6,129 lbs
- Max Available GCWR:
- 15,250 lbs
- Max Towing:
- 7,500 lbs [1]
- Fuel Tank Capacity:
- 24.5 gal
Measurements
- Standing Height:
- 77 in
- Cargo Bed Length:
- 144 in
- Turning Diameter (curb to curb):
- 52 ft
- Ground To First Step-Side:
- 22 in
- Load height, unloaded (ground to cargo floor):
- 29 in
- Door Opening-Side(Height):
- 72 in
- Door Opening-Rear(Height):
- 73 in
- Dual Door Width-Side:
- 51 in
- Door Width-Rear:
- 61 in
- Max. Cargo Bed Length:
- 144 in
- Cargo Width at Wheelhouse:
- 53 in
- Max Width at Floor:
- 70 in
Powertrain
- Engine:
- 4-Cylinder Diesel Standard Output
- Fuel Type:
- Diesel
- Displacement:
- 1,950 cc
- Horsepower:
- 170 hp
- Rated Torque:
- 295 lb-ft
- Transmission:
- Automatic Transmission, 9G-TRONIC
- Drive Shaft:
- RWD
- Emission Certification:
- SULEV
- Injection:
- Common-rail direct injection (CDI)

Crew Van 3500XD
Dimensions

- Overall Height:
- 109 in
- Overall Length:
- 274 in
- Overall Width with mirrors:
- 96 in
- Wheelbase:
- 170 in
Key Features
- Engine:
- 4-Cylinder Diesel High Output
- Payload Capacity:
- 4,901 lbs
- Max Towing:
- 7,500 lbs [1]
- Cargo Volume:
- 350 cu ft
- Standing Height:
- 77 in
- Seating Capacity:
- 5
Capacity
- Payload Capacity:
- 4,901 lbs
- Seating Capacity:
- 5
- Cargo Volume:
- 350 cu ft
- Max Available GVWR:
- 11,030 lbs
- Base Curb Weight:
- 6,129 lbs
- Max Available GCWR:
- 15,250 lbs
- Max Towing:
- 7,500 lbs [1]
- Fuel Tank Capacity:
- 24.5 gal
Measurements
- Standing Height:
- 77 in
- Cargo Bed Length:
- 144 in
- Turning Diameter (curb to curb):
- 52 ft
- Ground To First Step-Side:
- 22 in
- Load height, unloaded (ground to cargo floor):
- 29 in
- Door Opening-Side(Height):
- 72 in
- Door Opening-Rear(Height):
- 73 in
- Dual Door Width-Side:
- 51 in
- Door Width-Rear:
- 61 in
- Max. Cargo Bed Length:
- 144 in
- Cargo Width at Wheelhouse:
- 53 in
- Max Width at Floor:
- 70 in
Powertrain
- Engine:
- 4-Cylinder Diesel High Output
- Fuel Type:
- Diesel
- Displacement:
- 1,950 cc
- Horsepower:
- 211 hp
- Rated Torque:
- 332 lb-ft
- Transmission:
- Automatic Transmission, 9G-TRONIC
- Drive Shaft:
- RWD
- Emission Certification:
- SULEV
- Injection:
- Common-rail direct injection (CDI)

Crew Van 3500XD
Dimensions

- Overall Height:
- 111 in
- Overall Length:
- 274 in
- Overall Width with mirrors:
- 96 in
- Wheelbase:
- 170 in
Key Features
- Engine:
- 4-Cylinder Diesel high Output AWD
- Payload Capacity:
- 4,581 lbs
- Max Towing:
- 7,500 lbs [1]
- Cargo Volume:
- 350 cu ft
- Standing Height:
- 77 in
- Seating Capacity:
- 5
Capacity
- Payload Capacity:
- 4,581 lbs
- Seating Capacity:
- 5
- Cargo Volume:
- 350 cu ft
- Max Available GVWR:
- 11,030 lbs
- Base Curb Weight:
- 6,449 lbs
- Max Available GCWR:
- 15,250 lbs
- Max Towing:
- 7,500 lbs [1]
- Fuel Tank Capacity:
- 24.5 gal
Measurements
- Standing Height:
- 77 in
- Cargo Bed Length:
- 144 in
- Turning Diameter (curb to curb):
- 52 ft
- Ground To First Step-Side:
- 21 in
- Load height, unloaded (ground to cargo floor):
- 31 in
- Door Opening-Side(Height):
- 72 in
- Door Opening-Rear(Height):
- 73 in
- Dual Door Width-Side:
- 51 in
- Door Width-Rear:
- 61 in
- Max. Cargo Bed Length:
- 144 in
- Cargo Width at Wheelhouse:
- 39 in
- Max Width at Floor:
- 70 in
Powertrain
- Engine:
- 4-Cylinder Diesel high Output AWD
- Fuel Type:
- Diesel
- Displacement:
- 1,950 cc
- Horsepower:
- 211 hp
- Rated Torque:
- 332 lb-ft
- Transmission:
- Automatic Transmission,9G-TRONIC
- Drive Shaft:
- RWD
- Emission Certification:
- SULEV
- Injection:
- Common-rail direct injection (CDI)

Crew Van 4500
Dimensions

- Overall Height:
- 109 in
- Overall Length:
- 274 in
- Overall Width with mirrors:
- 96 in
- Wheelbase:
- 170 in
Key Features
- Engine:
- 4-Cylinder Diesel Standard Output
- Payload Capacity:
- 5,964 lbs
- Max Towing:
- 7,500 lbs [1]
- Cargo Volume:
- 350 cu ft
- Standing Height:
- 77 in
- Seating Capacity:
- 5
Capacity
- Payload Capacity:
- 5,964 lbs
- Seating Capacity:
- 5
- Cargo Volume:
- 350 cu ft
- Max Available GVWR:
- 12,125 lbs
- Base Curb Weight:
- 6,162 lbs
- Max Available GCWR:
- 15,250 lbs
- Max Towing:
- 7,500 lbs [1]
- Fuel Tank Capacity:
- 24.5 gal
Measurements
- Standing Height:
- 77 in
- Cargo Bed Length:
- 144 in
- Turning Diameter (curb to curb):
- 52 ft
- Ground To First Step-Side:
- 21 in
- Load height, unloaded (ground to cargo floor):
- 29 in
- Door Opening-Side(Height):
- 72 in
- Door Opening-Rear(Height):
- 73 in
- Dual Door Width-Side:
- 51 in
- Door Width-Rear:
- 61 in
- Max. Cargo Bed Length:
- 144 in
- Cargo Width at Wheelhouse:
- 39 in
- Max Width at Floor:
- 70 in
Powertrain
- Engine:
- 4-Cylinder Diesel Standard Output
- Fuel Type:
- Diesel
- Displacement:
- 1,950 cc
- Horsepower:
- 170 hp
- Rated Torque:
- 295 lb-ft
- Transmission:
- Automatic Transmission,9G-TRONIC
- Drive Shaft:
- RWD
- Emission Certification:
- SULEV
- Injection:
- Common-rail direct injection (CDI)
Dimensions

- Overall Height:
- 109 in
- Overall Length:
- 274 in
- Overall Width with mirrors:
- 96 in
- Wheelbase:
- 170 in
Key Features
- Engine:
- 4-Cylinder Diesel High Output
- Payload Capacity:
- 5,964 lbs
- Max Towing:
- 7,500 lbs [1]
- Cargo Volume:
- 350 cu ft
- Standing Height:
- 77 in
- Seating Capacity:
- 5
Capacity
- Payload Capacity:
- 5,964 lbs
- Seating Capacity:
- 5
- Cargo Volume:
- 350 cu ft
- Max Available GVWR:
- 12,125 lbs
- Base Curb Weight:
- 6,162 lbs
- Max Available GCWR:
- 15,250 lbs
- Max Towing:
- 7,500 lbs [1]
- Fuel Tank Capacity:
- 24.5 gal
Measurements
- Standing Height:
- 77 in
- Cargo Bed Length:
- 144.in
- Turning Diameter (curb to curb):
- 52 ft
- Ground To First Step-Side:
- 21 in
- Load height, unloaded (ground to cargo floor):
- 29 in
- Door Opening-Side(Height):
- 72 in
- Door Opening-Rear(Height):
- 73 in
- Dual Door Width-Side:
- 51 in
- Door Width-Rear:
- 61 in
- Max. Cargo Bed Length:
- 144 in
- Cargo Width at Wheelhouse:
- 39 in
- Max Width at Floor:
- 70 in
Powertrain
- Engine:
- 4-Cylinder Diesel High Output
- Fuel Type:
- Diesel
- Displacement:
- 1,950 cc
- Horsepower:
- 211 hp
- Rated Torque:
- 332 lb-ft
- Transmission:
- Automatic Transmission,9G-TRONIC
- Drive Shaft:
- RWD
- Emission Certification:
- SULEV
- Injection:
- Common-rail direct injection (CDI)
Key Features
More Than a Van

Upfit Your Van with Mercedes-Benz ExpertSOLUTIONS
No van upfits like a Mercedes-Benz Sprinter van. Whether for business or pleasure, Mercedes-Benz vans offer superior capabilities designed to fit your needs, no matter what they may be.

Connected Technology for Your Sprinter
With technology like Active Brake Assist, rear-view camera display, multimedia touch-screen control and more, you’ll be taking to the road with ease. And when you connect drivers, vehicles, and managers with Mercedes me connect, you can push your business even further.[2][3]

Value for the Long Haul
Compare the Total Cost of Operation between Mercedes-Benz Vans and other competitors to see for yourself.
Gallery
