Passenger Van

Starting at

You focus on work. We’ll focus on safety.

At Mercedes-Benz, we’re constantly developing new innovations to make sure your job gets done as safely as possible.
Watch Video


Watch Video
x of x

Passenger Van Specs

Choose a Wheelbase

170 Extended

Choose a Height

Standard Roof
High Roof

Choose a Powertrain

6 Cylinder
6 Cylinder 4x4

Choose a Payload

3,083 lbs
4,082 lbs
4,364 lbs
5,133 lbs

Gross Vehicle Weight Rating



Maximum Seating Capacity

Up to 12


Maximum Payload Capacity



Maximum Towing Capacity



Cargo Volume


cu ft.

Int. Standing Height




Sprinter Passenger Van
2500 High Roof 144 Wheelbase

Overall Height: 110.5 in

Overall Length: 233.3 in

Overall Width with mirrors: 95.5 in

Wheel base: 144.3 in

Key Features

Engine: 4-Cylinder Diesel

Max Payload Capacity: 2,697 lbs

Max Towing Capacity: 5,000 lbs

Cargo Volume: 80.8 cu ft

Int. Standing Height: 75.5 in

Max Seating Capacity: Up to 12


Max Available GVWR: 8,550 lbs

Base Curb Weight: 5,853 lbs

Max Payload: 2,697 lbs

Max Available GCWR: 13,550 lbs

Max Towing: 5,000 lbs

Fuel Tank Capacity: 24.5 gal


Turning Diameter (Curb to Curb): 44.6 ft

Ground To First Step-Side: 20.0 in

Load Height-Rear: 27.0 in

Door Opening-Side(Height): 71.7 in

Door Opening-Rear(Height): 72.4 in

Dual Door Width-Side: 51.2 in

Door Width-Rear: 61.5 in

Cargo Bed Length: 33.7 in

Cargo Width at Wheelhouse: 53.1 in

Max Width at Floor: 70.1 in


Engine: 4-Cylinder Diesel

Fuel Type: Diesel

Displacement: 2,143 cc

Horsepower: 161 hp at 3800 rpm

Rated Torque: 265 lb-ft at 1,400-2,400 rpm

Transmission: 7-Speed 7G-TRONIC

Drive Shaft: Rear-wheel drive

Emission Certification: Low-emission EPA14/carb certified

See all Specs Hide Specs

The Passenger Van Lineup


Passenger Van 2500
Starting at: $47,185*
See All Models Hide
High Roof - 144" Wheelbase
Starting at: $47,185*
High Roof - 170" Wheelbase
Starting at: $50,680*
High Roof - 144" Wheelbase 4x4
Starting at: $54,755*

Special Offers

2017 Sprinter Cargo Van

$529/month lease for 48 months!56
Take advantage of this special lease FMV offer of $529/month56 for 48 months, including complimentary VanCARE Lease-End Protection55.

Offer Details View All Offers

The best-size van is the right size for the job.

Explore Metris
*Excludes all options, taxes, title, registration, transportation charge and dealer prep fee. Options shown. Not all options are available in the U.S. For a full offering and pricing information, visit your local Mercedes-Benz Vans dealership. Delayed availability.
