Cargo Van

Starting at
$37,995*

You focus on work. We’ll focus on safety.

At Mercedes-Benz, we’re constantly developing new innovations to make sure your job gets done as safely as possible.
Watch Video

Safety

Watch Video
x of x

Cargo Van Specs


Choose a Wheelbase

144
170
170 Extended

Choose a Height

Standard Roof
High Roof

Choose a Powertrain

6 Cylinder
6 Cylinder 4x4

Choose a Payload

3,083 lbs
4,082 lbs
4,364 lbs
5,133 lbs

Gross Vehicle Weight Rating

8,550

lbs.

Maximum Seating Capacity

Up to 3

people

Maximum Payload Capacity

3,512

lbs.

Maximum Towing Capacity

5,000

lbs.22

Cargo Volume

319.1

cu ft.

Int. Standing Height

66.5

in.

Dimensions


Sprinter Cargo Van
2500 Standard Roof 144 Wheelbase

Overall Height: 94.5 in

Overall Length: 233.3 in

Overall Width with mirrors: 95.5 in

Wheel base: 144.3 in

Key Features


Engine: 4-Cylinder Diesel

Max Payload Capacity: 3,512 lbs

Max Towing Capacity: 5,000 lbs22

Cargo Volume: 319.1 cu ft

Int. Standing Height: 66.5 in

Max Seating Capacity: Up to 3

Capacity


Max Available GVWR: 8,550 lbs

Base Curb Weight: 5,038 lbs

Max Payload: 3,512 lbs

Max Available GCWR: 13,550 lbs

Max Towing: 5,000 lbs22

Fuel Tank Capacity: 24.5 gal

Measurements


Turning Diameter (curb to curb): 44.6 ft

Ground To First Step-Side: 20.5 in

Load Height-Rear: 27.9 in

Door Opening-Side(Height): 59.8 in

Door Opening-Rear(Height): 60.6 in

Dual Door Width-Side: 51.2 in

Door Width-Rear: 61.5 in

Cargo Bed Length: 137.4 in

Cargo Width at Wheelhouse: 53.1 in

Max Width at Floor: 70.1 in

Powertrain


Engine: 4-Cylinder Diesel

Fuel Type: Diesel

Displacement: 2,143 cc

Horsepower: 161 hp at 3800 rpm

Rated Torque: 265 lb-ft at 1,400-2,400 rpm

Transmission: 7-Speed 7G-TRONIC

Drive Shaft: Rear-wheel drive

Emission Certification: Low-emission EPA14/carb certified

See all Specs Hide Specs

The Cargo Van Lineup


2500

Cargo Van 2500
Starting at: $37,995*
Build
See All Models Hide
Standard Roof - 144" Wheelbase
Starting at: $37,995*
Build
High Roof - 144" Wheelbase
Starting at: $40,495*
Build
High Roof - 170" Wheelbase
Starting at: $42,795*
Build
High Roof - 170" Wheelbase Extended
Starting at: $44,395*
Build
Standard Roof - 144" Wheelbase 4x4
Starting at: $45,490*
Build
High Roof - 144" Wheelbase 4x4
Starting at: $47,990*
Build
High Roof - 170" Wheelbase 4x4
Starting at: $50,290*
Build
High Roof - 170" Wheelbase Extended 4x4
Starting at: $51,890*
Build

3500

Cargo Van 3500
Starting at: $42,695*
Build
See All Models Hide
High Roof - 144" Wheelbase
Starting at: $42,695*
Build
High Roof - 170" Wheelbase
Starting at: $44,995*
Build
High Roof - 170" Wheelbase Extended
Starting at: $46,595*
Build
Super High Roof - 170" Wheelbase
Starting at: $49,495*
Build
Super High Roof - 170" Wheelbase Extended
Starting at: $51,095*
Build
High Roof - 144" Wheelbase 4x4
Starting at: $52,190*
Build
High Roof - 170" Wheelbase 4x4
Starting at: $54,490*
Build
High Roof - 170" Wheelbase Extended 4x4
Starting at: $56,090*
Build
